System and opening types
Aluminium window, Schüco AWS platform, 50 mm basic depth; inward and outward-opening; side-hung, turn/tilt, bottom-hung toplight, double-vent, barrier-free window doors.
Windows · Schüco aluminium system
Window System AWS 50 / AWS 50.NI
Overview
Schüco AWS 50 is the thermally insulated standard aluminium window system for the 50 mm basic depth, built on the Schüco AWS system platform. It supports punched openings, ribbon windows and façade insert units, inward and outward-opening designs, and side-hung, turn/tilt, bottom-hung and barrier-free configurations. Concealed AvanTec SimplySmart fittings allow large vent weights and a 180° opening angle. A non-insulated AWS 50.NI variant is available for interiors and warm climates.
Availability and final specification to be confirmed with KR.
Bookmarks and comparisons are saved on this device. Open Windows & Doors to compare systems side by side.
Spotlight on:
Product highlights
Published Schüco system characteristics for the Window System AWS 50 / AWS 50.NI:
Product highlights in detail
Configuration and planning
Punched opening, ribbon window, façade insert unit; combination with Schüco door systems; AWS 50 RL Residential Line; insert outer frames with adapter gasket.
System integration
Schüco AvanTec SimplySmart fittings; Schüco door systems; Schüco mullion/transom façades; Schüco sun shading (CTB on AWS) and ventilation systems.
Key system data
- Burglary Resist: RC 1
- Aluminium: 50 mm
- Double Glazing
- Max Height: 2000 mm
- Max Weight: 160 kg
- Face Width: 84 mm
- Ventilation
01 — Planning benefit
Planning benefit
Aluminium window, Schüco AWS platform, 50 mm basic depth; inward and outward-opening; side-hung, turn/tilt, bottom-hung toplight, double-vent, barrier-free window doors; AWS 50.NI adds tilt/slide and projected top-hung
Punched opening, ribbon window, façade insert unit
Combination with Schüco door systems
AWS 50 RL Residential Line
Insert outer frames with adapter gasket
Corner, structural, symmetrical and asymmetrical mullions
02 — System integration
System integration
Schüco AvanTec SimplySmart fittings
Schüco door systems
Schüco mullion/transom façades
Schüco sun shading (CTB on AWS) and ventilation systems
Schüco VentoFrame Asonic compatible
03 — Gallery
Gallery
04 — Awards
Awards
-
Cradle to Cradle Certified Silver
05 — Technical information
Technical information
Figures are published system maxima and minima. “Not published” means Schüco publishes no figure for that property; project values depend on configuration, glazing build-up and installation, and are confirmed by KR at tender.
Dimensions and profile
| Basic depth (mm) | 50 |
|---|---|
| Max. vent size, W × H (mm) | AWS 50.NI: 1300 × 1800 (side-hung), 1800 × 2000 (top-hung); AWS 50: not published |
| Max. vent weight (kg) | AWS 50.NI: 130 (SH) / 160 (TH); AWS 50: not published |
| Face width (mm) | AWS 50.NI: min 84 |
| Glazing thickness (mm) | AWS 50.NI: 6–42 |
Performance
| Thermal performance | Not published |
|---|---|
| Sound reduction | Not published |
| Watertightness | AWS 50.NI: class 9A (600 Pa) |
| Air permeability | AWS 50.NI: class 4 (600 Pa) |
| Wind load resistance | AWS 50.NI: class C5 (2000 Pa) |
Security and function
| Burglar resistance | AWS 50: DIN EN 1627, plus PAS 24 for outward-opening centre-gasket double-vent; AWS 50.NI: RC 1 |
|---|---|
| Threshold and accessibility | barrier-free window doors available |
| Further features | 180° opening angle with concealed AvanTec SimplySmart fitting; AWS 50.NI safety catch and engagement catch for high winds |
06 — Documentation
Documentation
Access required Schüco publishes Window System AWS 50 / AWS 50.NI technical documentation behind a registered architect login. The files are not downloadable from this page.
KR holds current documentation as a Schüco fabrication and installation partner and will supply the relevant sheets for a nominated project — or arrange authorised access through Schüco's architect workplace.
07 — Specification texts
Specification texts
Specification summary for the Schüco Window System AWS 50 / AWS 50.NI. The complete, tender-ready specification text is issued by KR for a nominated project.
- Basic depth (mm): 50
- Face width (mm): AWS 50.NI: min 84
- Glazing thickness (mm): AWS 50.NI: 6–42
- Watertightness: AWS 50.NI: class 9A (600 Pa)
- Air permeability: AWS 50.NI: class 4 (600 Pa)
- Wind load resistance: AWS 50.NI: class C5 (2000 Pa)
- Burglar resistance: AWS 50: DIN EN 1627, plus PAS 24 for outward-opening centre-gasket double-vent; AWS 50.NI: RC 1
- Threshold and accessibility: barrier-free window doors available
- Further features: 180° opening angle with concealed AvanTec SimplySmart fitting; AWS 50.NI safety catch and engagement catch for high winds
08 — CAD data
CAD data
Access required Schüco releases Window System AWS 50 / AWS 50.NI CAD sections and BIM objects only to registered architects through its architect workplace. No CAD or BIM files are hosted on this page.
KR can issue the relevant sections and details for a nominated project, or help set up authorised Schüco access for your practice.
09 — Brochures
Brochures
Published Schüco literature covering the Window System AWS 50 / AWS 50.NI. KR supplies current editions directly.
Schüco AWS 50.NI product brochure
Current edition supplied by KR on request.
Specifying Window System AWS 50 / AWS 50.NI?
KR fabricates, installs and distributes the Schüco range Australia wide. Talk to our team about configurations, thresholds, glazing build-ups and site conditions.
