System and opening types
Aluminium hinged door, AD UP platform, 90 mm basic depth; triple-shell construction with a continuous double centre gasket.
Hinged doors · Schüco aluminium system
Door System AD UP 90
Overview
Schüco AD UP 90 is the 90 mm aluminium door system in the Schüco Aluminium Door Universal Platform — super insulated for projects with extra energy or acoustic requirements, and aimed at demanding project-specific solutions in residential and commercial construction. A triple-shell construction with a continuous double centre gasket delivers strong energy, insulation and weathertightness performance. The AD UP 90.SI variant reaches Uf values at passive house level and integrates automation components via a profile-integrated cable groove.
Availability and final specification to be confirmed with KR.
Bookmarks and comparisons are saved on this device. Open Windows & Doors to compare systems side by side.
Spotlight on:
Product highlights
Published Schüco system characteristics for the Door System AD UP 90:
Product highlights in detail
Configuration and planning
Front entrance doors with leaf-enclosing infills on one or both sides; framed infills; mounted infills with adhesive-free mechanical fixing (BL Residential).
System integration
Part of the Schüco AD UP Universal Platform, compatible across basic depths with the corresponding Schüco façades and Schüco windows including sidelights and toplights.
Key system data
- Burglary Resist: RC 2
- Acoustic Cont: Rw 42 dB
- Aluminium: 90 mm
- Double Glazing
- Triple Glazing
- Max Height: 2500 mm
- Automation
01 — Planning benefit
Planning benefit
Aluminium hinged door, AD UP platform, 90 mm basic depth; triple-shell construction with a continuous double centre gasket; front entrance with leaf-enclosing infills, concealed hinges and concealed integrated door communication
Front entrance doors with leaf-enclosing infills on one or both sides
Framed infills
Mounted infills with adhesive-free mechanical fixing (BL Residential)
Concealed fixing to building structure
Harmonious smooth door rebate look
Range of vent types
02 — System integration
System integration
Part of the Schüco AD UP Universal Platform, compatible across basic depths with the corresponding Schüco façades and Schüco windows including sidelights and toplights
Concealed integrated door communication
Automation components via profile-integrated cable groove
AD UP 90 Design Edition with BlueCon is a built showroom configuration
03 — Gallery
Gallery
04 — Awards
Awards
-
Cradle to Cradle Certified Silver
05 — Technical information
Technical information
Figures are published system maxima and minima. “Not published” means Schüco publishes no figure for that property; project values depend on configuration, glazing build-up and installation, and are confirmed by KR at tender.
Dimensions and profile
| Basic depth (mm) | 90 |
|---|---|
| Max. leaf size, W × H (mm) | 1250 × 2500 (width x height) |
| Max. leaf weight (kg) | Not published |
| Face width (mm) | Not published |
| Infill thickness (mm) | Not published |
Performance
| Thermal performance | AD UP 90: Uf to 1.3 W/(m²K); AD UP 90.SI: Uf values to passive house level (no number published) |
|---|---|
| Sound reduction | 42 |
| Watertightness | Not published |
| Air permeability | Not published |
| Wind load resistance | Not published |
Security and function
| Burglar resistance | up to RC 2; AD UP 90 BL Residential offers class RC 2 in its mechanical infill fastener portfolio |
|---|---|
| Threshold and accessibility | AD UP 90.SI easy-access threshold solutions to DIN 18040 as aluminium and plastic thresholds |
| Automation | profile-integrated cable groove as standard for automation components; operation manual or automated |
| Further features | mechanical durability to 1 million cycles; concealed hinges with door communication and access control; AD UP 90 BL Residential is a KfW-eligible solution for energy efficiency, burglar resistance and ease of access |
06 — Documentation
Documentation
Access required Schüco publishes Door System AD UP 90 technical documentation behind a registered architect login. The files are not downloadable from this page.
KR holds current documentation as a Schüco fabrication and installation partner and will supply the relevant sheets for a nominated project — or arrange authorised access through Schüco's architect workplace.
07 — Specification texts
Specification texts
Specification summary for the Schüco Door System AD UP 90. The complete, tender-ready specification text is issued by KR for a nominated project.
- Basic depth (mm): 90
- Max. leaf size, W × H (mm): 1250 × 2500 (width x height)
- Thermal performance: AD UP 90: Uf to 1.3 W/(m²K); AD UP 90.SI: Uf values to passive house level (no number published)
- Sound reduction: 42
- Burglar resistance: up to RC 2; AD UP 90 BL Residential offers class RC 2 in its mechanical infill fastener portfolio
- Threshold and accessibility: AD UP 90.SI easy-access threshold solutions to DIN 18040 as aluminium and plastic thresholds
- Automation: profile-integrated cable groove as standard for automation components; operation manual or automated
- Further features: mechanical durability to 1 million cycles; concealed hinges with door communication and access control; AD UP 90 BL Residential is a KfW-eligible solution for energy efficiency, burglar resistance and ease of access
08 — CAD data
CAD data
Access required Schüco releases Door System AD UP 90 CAD sections and BIM objects only to registered architects through its architect workplace. No CAD or BIM files are hosted on this page.
KR can issue the relevant sections and details for a nominated project, or help set up authorised Schüco access for your practice.
09 — Brochures
Brochures
Published Schüco literature covering the Door System AD UP 90. KR supplies current editions directly.
Schüco AD UP 90.SI entrance-door brochure (P4484)
Current edition supplied by KR on request.
Schüco door-system brochure
Current edition supplied by KR on request.
Specifying Door System AD UP 90?
KR fabricates, installs and distributes the Schüco range Australia wide. Talk to our team about configurations, thresholds, glazing build-ups and site conditions.
Enquire with KR Back to Windows & Doors
Schüco is a registered trade mark of Schüco International KG. Values are indicative and depend on configuration, glazing and installation.
